►按最新环保，安规要求设计
Designing comply with request of the latest
environment and certificate
►高功率密度/High power density:140mm*100mm*22mm
►防潮处理/Damp proofing
►LED电源显示/LED Display
►漏电流小于0.3mA
Leakage Current: Less than 0.5mA
►符合海拔5000m高度要求
Altitude:5000m
►300VAC输入10S内机台无损坏
No damage with input 300VAC at 10s
►自然风冷散热
Ventilation cooling
►EMC符合：GB9254，EN55022A CLASSB
Complied with EMC standards:GB9254/EN55022A CLASSB
|
型号/Model |
项目/Item |
P4.2 |
P4.6 |
P5 |
P7.5 |
P12 |
|
输出 |
直流电压/DC Voltage |
4.2V |
4.6V |
5V |
7.5V |
12V |
|
电流范围/Current Range |
0-30A |
0-30A |
0-30A |
0-20A |
0-12.5A |
|
|
额定功率/Rated Power |
125W |
160W |
150W |
150W |
150W |
|
|
纹波与噪声/Ripple & Noise |
200mV |
200mV |
250mV |
300mV |
300mV |
|
|
电压精度/Voltage Tolerance |
±3% |
±3% |
±3% |
±3% |
±3% |
|
|
输入 |
电压范围/Voltage Range |
90-264V |
90-264V |
90-264V |
90-264V |
90-264V |
|
效率/Efficiency |
87% |
88% |
89% |
90% |
91% |
|
|
浪涌电流/Inrush Current |
30A |
30A |
30A |
30A |
30A |
|
|
PF值/PF Factor |
≥0.95 |
≥0.95 |
≥0.95 |
≥0.95 |
≥0.95 |
|
|
保护 |
过负载/Over Load |
120%-180%过流，故障排除可恢复 Over current 120%~180%,can auto-recover remove abnormal |
||||
|
过电压/Over Voltage |
LATCH OFF |
|||||
|
过温度/Over Temperature |
可恢复/Recover |
|||||
|
环境 |
工作温度/Operating Temperature |
-40℃-70℃（180-264V可支持到-50℃/Can work well at -50℃ when voltage rang is 180-264V） |
||||
|
储存温度/Storage Temperature |
-40℃-85℃ |
|||||
|
Certificates |
||||||
|
备注 |
1.如未特殊说明，所有规格参数均在输入220Vac，额定负载，25度环境温度下进行量测/All spec. will be tested at input 220V,rate loading,25 ℃ ambient temperature if without special notice |
|||||
|
2.在实际应用中需参考温度降额曲线及输入电压降额曲线/User need to refer temperature drop curve and input voltage drop curve |
||||||
|
3.有高性价比配置可选择/Cost effective and can select different configuration |
||||||
