特性/Characteristic:
►按最新环保，安规要求设计
Designing comply with request of the latest
environment and certificate
►高功率密度/High power density:190mm×84mm×30mm
►防潮处理/Damp proofing
►LED电源显示/LED Display
►漏电流小于0.5mA
Leakage Current: Less than 0.5mA
►符合海拔5000m高度要求
Altitude:5000m
►270VAC输入10S内机台无损坏
No damage with input 270VAC at 10s
►自然风冷散热
Ventilation cooling
►EMC符合：GB9254，EN55022A CLASSB
Complied with EMC standards:GB9254，EN55022A CLASSB
型号/Model
项目/Item
200WLL-200W
200WLH-200W
输出
Output
直流电压/DC Voltage
5V
12V
5V
12V
电流范围/Current
Range
0-40A
0-16.6A
0-40A
0-16.6A
额定功率/Rated Power
200W
200W
纹波与噪声/Ripple
& Noise
300mV
300mV
300mV
300mV
电压精度/Voltage
Tolerance
±5%
±5%
±5%
±5%
输入
Input
电压范围/Voltage
Range
100-120V
100-120V
200-240V
200-240V
效率/Efficiency
85%
86%
86%
88%
浪涌电流/Inrush
Current
30A
30A
30A
30A
PF值/PF Factor
≥0.5
≥0.5
≥0.5
≥0.5
保护
Protection
过负载/Over Load
120%-180%过流，故障排除可恢复Over current 120%~180%,can auto-recover
remove abnormal
过电压/Over
Voltage
LATCH OFF
过温度/Over
Temperature
故障排除可恢复/Can auto-recover after remove abnormal.
环境
Environment
工作温度/Operating
Temperature
-20℃-40℃
储存温度/Storage
Temperature
-40℃-85℃
备注
Remark
1.如未特殊说明，所有规格参数均在输入100Vac/220Vac，额定负载，25度环境温度下进行量测/All spec. will be tested at input110Vac/ 220V,rate loading,25 ℃ ambient temperature if without
special notice
2.在实际应用中需参考温度降额曲线及输入电压降额曲线/User need to refer temperature drop
curve and input voltage drop curve
3.此机型可支持单路输出。/This power supply support single output
